Square-D / Schneider - SQD LP1K09008JD CONTACTOR 600VAC 9A
Login or create an account to check prices & order
Essential specifications
12-Digit UPC - 785901790297
Applications - LP1K,RESISTIVE LOAD
Catalog Number - LP1K09008JD
Coil Voltage - 12 VDC
Country of Origin - France
Packaging
1 ea
EAN
00785901790297
Part #
101146
Catalog #
LP1K09008JD
Commercial reference
LP1K09008JD
12-Digit UPC:
785901790297
Applications:
LP1K,RESISTIVE LOAD
Catalog Number:
LP1K09008JD
Coil Voltage:
12 VDC
Country of Origin:
France
Depths:
57 mm
ERP_productname:
SQD LP1K09008JD CONTACTOR 600VAC 9AMP IEC +OPTIONS DISCONTINUED
Family Brand Name:
Schneider Electric
Heights:
58 mm
Impedance:
3 MOhm - Ith 20 A 50 Hz Power Circuit
Size:
4P
Sub Brand:
TESYS,TESYS K
Type:
LP1K,CONTACTOR
Voltage:
690 Volt
Widths:
45 mm
SoneparProductId:
SKU_US_132273396
TeSys K contactor, 4 poles (2NO+2NC), for non-inductive load control applications up to 20A/690V AC-1. It provides a 12V DC coil, without built-in auxiliary contact, connection by screw clamp terminals. For operating rates until 600 cycles/hour and environments until 50.C, it procures reliability and durability to standard applications. Very compact (45mm width), DIN-rail mounting or screw fixing. Multi standards certified (IEC, UL, CSA, CCC, EAC), Green Premium compliant (RoHS/REACh).
