Square-D / Schneider - SQD PLL34000S80 Automatic switch, P
Login or create an account to check prices & order
Essential specifications
12-Digit UPC - 785901658542
Amperage - 800 Amp
Catalog Number - PLL34000S80
Circuit Breaker Type - P-Frame
Country of Origin - USA
Packaging
1 ea
EAN
00785901658542
Part #
115823
Catalog #
PLL34000S80
Commercial reference
PLL34000S80
12-Digit UPC:
785901658542
Amperage:
800 Amp
Catalog Number:
PLL34000S80
Circuit Breaker Type:
P-Frame
Country of Origin:
USA
Depths:
14.49 Inch
ERP_productname:
SQD PLL34000S80 AUTOMATIC MOLDED CASE SWITCH 480V 800A
Family Brand Name:
Square D
Heights:
16.24 Inch
Mounting Type:
Unit Mount
Size:
14.49 in
Tc Connection:
AWG 3/0...500 KCMIL ALUMINIUM/COPPER)3,LUGS LINE-LUGS LOAD
Type:
Automatic switch
Voltage:
480 Volt
Widths:
16.54 in
SoneparProductId:
SKU_US_75321749
The automatic switches are similar in construction to, use the same accessories, and offer the same connection possibilities as the P-Frame circuit breaker version. The switches have a factory set, nonadjustable trip point calibrated to protect the molded case switch. This unit has lugs on both the line and load sides. This PowerPacT P, 800A, 3 pole, automatic switch has a withstand current rating of 100kA at 480VAC. PowerPacT P automatic switches comply to UL and CSA standards.
