Square-D / Schneider - Square D 8501CO16V08 208 VAC 30 Amp 2-Pole DPDT 2NO 2NC Panel Mount AC Operated Power Relay
Login or create an account to check prices & order
Essential specifications
12-Digit UPC - 785901052142
Catalog Number - 8501CO16V08
Country of Origin - China
Depths - 2.31 Inch
ERP_productname - SQD 8501CO16V08 RELAY 600VAC 5AMP TYPE C +OPTIONS
Packaging
1 ea
EAN
00785901052142
Part #
144746
Catalog #
8501CO16V08
Commercial reference
8501CO16V08
12-Digit UPC:
785901052142
Catalog Number:
8501CO16V08
Country of Origin:
China
Depths:
2.31 Inch
ERP_productname:
SQD 8501CO16V08 RELAY 600VAC 5AMP TYPE C +OPTIONS
Family Brand Name:
Square D
Heights:
3.12 Inch
Number of Phases:
1 Phase
Sub Brand:
TYPE C
Type:
POWER RELAY
Widths:
2.5 in
SoneparProductId:
SKU_US_26892665
8501C power relays are used to control small single phase motors and other light loads. These power relays are available with a variety of contact configurations. This relay has a DPDT contact configuration with two normally open and two normally closed contact. A variety of coil voltages are available. This relay has a 208 VAC nonreplaceable coil. Designed with heavy duty contacts that are rated for single phase 1.5 HP motors at 120 VAC, 230 VAC or 600 VAC. It also has a 30 A resistive rating at 300 VAC or 5 A resistive rating at 600 VAC. These relays have a durable open frame construction. 8501C power relays are UL listed and CSA certified. This range of relays is used in electric heater, pumping, conveyor and material handling applications.
