Square-D / Schneider - Square D 8501RS34V14 24 VAC 5 Amp 4PDT 4CO Socket Mount AC Operated Miniature Plug-In Relay
Login or create an account to check prices & order
Essential specifications
12-Digit UPC - 785901031871
Amperage - 5 Amp
Applications - 8501NR45
Catalog Number - 8501RS34V14
Country of Origin - China
Packaging
1 ea
EAN
00785901031871
Part #
152837
Catalog #
8501RS34V14
Commercial reference
8501RS34V14
12-Digit UPC:
785901031871
Amperage:
5 Amp
Applications:
8501NR45
Catalog Number:
8501RS34V14
Country of Origin:
China
Depths:
38.9 mm
ERP_productname:
SQD 8501RS34V14 RELAY 24VAC 5AMP TYPE R +OPTIONS
Family Brand Name:
Square D
Heights:
29.4 mm
Mounting Type:
Socket
Tc Connection:
SPADE
Type:
Miniature Relay;Low voltage;4PDT
Widths:
23.1 mm
SoneparProductId:
SKU_US_26890639
8501RS miniature plug in relays are designed for use in Class 1 Division 2 hazardous locations. These relays are designed to be plugged into a relay socket. This makes for very easy replacement. This relay plugs into an 8501NR45 or 8501NR45B relay socket. Relay is available with 4PDT contact arrangements. It has four normally open and four normally closed contacts. The contacts have a 5 ampere resistive rating at 240 VAC, at 120 VAC and at 30 VDC. Relays can be ordered with a wide variety of coil voltages. This relay has a 24 VAC nonreplaceable coil. Relay does not have a green LED indicator. 8501RS relays are UL listed with Square D relay sockets, UL component recognized and CSA certified.
