Square-D / Schneider - Square D 8903SQO10V02 100 Amp 600 VAC Lighting Contactor NEMA Push Button
Login or create an account to check prices & order
Essential specifications
12-Digit UPC - 785901861980
Applications - MECHANICALLY HELD
Catalog Number - 8903SQO10V02
Coil Voltage - 120@60Hz to 110@50Hz VAC
Country of Origin - USA
Packaging
1 ea
EAN
00785901861980
Part #
225374
Catalog #
8903SQO10V02
Commercial reference
8903SQO10V02
12-Digit UPC:
785901861980
Applications:
MECHANICALLY HELD
Catalog Number:
8903SQO10V02
Coil Voltage:
120@60Hz to 110@50Hz VAC
Country of Origin:
USA
Current:
100 Amp
Depths:
171 mm
ERP_productname:
SQD 8903SQO10V02 LIGHTING CONTACTOR 600VAC 100A NEMA
Family Brand Name:
Square D
Heights:
257 mm
Number of Poles:
2 Pole
Size:
6.73 in
Sub Brand:
8903S
Tc Connection:
Lugs
Type:
Mechanically Held Lighting Contactor
Widths:
151 mm
SoneparProductId:
SKU_US_26318581
8903S lighting contactors are for lighting control applications. 8903S lighting contactors are available in either mechanically held or electrically held versions. This is a mechanically held device. This contactor is designed to switch 100 amperes. This device 2 pole device has 2 NO contacts. Supplied with a 110/120 VAC 50/60 Hz interchangeable operating coil but other coils are available in a wide variety of common voltages up to 600VAC. Contactor is an open device. A variety of enclosure types are available. Coil and contacts are easily replaced. Lighting contactor is 10.13 inches tall, 5.94 inches wide and 6.72 inches deep. 8903L lighting contactors are UL Listed and CSA Certified. Prop 65: WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov - Compatible Products: 9999SX6; 9999SX7; 9999SX8
