Square-D / Schneider - Square D 8903SXO2V02 110/120 VAC 300 Amp 3-Pole Open Type Electrically Held Lighting Contactor
Login or create an account to check prices & order
Essential specifications
12-Digit UPC - 785901166122
Applications - ELECTRICALLY HELD
Catalog Number - 8903SXO2V02
Coil Voltage - 120@60Hz to 110@50Hz VAC
Country of Origin - Mexico
Packaging
1 ea
EAN
00785901166122
Part #
120705
Catalog #
8903SXO2V02
Commercial reference
8903SXO2V02
12-Digit UPC:
785901166122
Applications:
ELECTRICALLY HELD
Catalog Number:
8903SXO2V02
Coil Voltage:
120@60Hz to 110@50Hz VAC
Country of Origin:
Mexico
Current:
300 Amp
Depths:
222 mm
ERP_productname:
SQD 8903SXO2V02 LIGHTING CONTACTOR 600VAC 300A NEMA
Family Brand Name:
Square D
Heights:
313 mm
Number of Poles:
3 Pole
Size:
8.74 in
Sub Brand:
8903S
Tc Connection:
Lugs
Type:
Electrically Held Lighting Contactor
Widths:
220 mm
SoneparProductId:
SKU_US_26271254
8903S lighting contactors are for lighting control applications. 8903S lighting contactors are available in either mechanically held or electrically held versions. This is an electrically held device. This contactor is designed to switch 300 amperes. This device 3 pole device has 3 NO contacts. Supplied with a 110/120 VAC 50/60 Hz interchangeable operating coil but other coils are available in a wide variety of common voltages up to 600VAC. Contactor is an open device. A variety of enclosure types are available. Coil and contacts are easily replaced. Lighting contactor is 12.25 inches tall, 8.66 inches wide and 8.74 inches deep. 8903L lighting contactors are UL Listed and CSA Certified. Compatible Products: 9999SX6; 9999SX7; 9999SX8
