Square-D / Schneider - Square D 9007MS02G0300 125 VAC 28 VDC 100/30 mA SPDT Snap Action Encapsulated Miniature Heavy Duty Limit Switch
Login or create an account to check prices & order
Essential specifications
12-Digit UPC - 785901724278
Actuator - SPRING RETURN PARALLEL ROLLER PLUNGER STEEL -
Amperage - 10 Amp
Applications - 9007MS/ML,MINIATURE POTTED,PLUNGER HEAD
Catalog Number - 9007MS02G0300
Packaging
1 ea
EAN
00785901724278
Part #
190992
Catalog #
9007MS02G0300
Commercial reference
9007MS02G0300
12-Digit UPC:
785901724278
Actuator:
SPRING RETURN PARALLEL ROLLER PLUNGER STEEL -
Amperage:
10 Amp
Applications:
9007MS/ML,MINIATURE POTTED,PLUNGER HEAD
Catalog Number:
9007MS02G0300
Country of Origin:
Mexico
Depths:
0.62 Inch
ERP_productname:
SQD 9007MS02G0300 LIMIT SWITCH 240VAC 10AMP MS +OPTIONS
Enclosure:
NEMA 1 NEMA TYPE 250-NEMA 2 NEMA TYPE 250-NEMA 4 NEMA TYPE 250-NEMA 6 NEMA TYPE 250-NEMA 6P NEMA TYPE 250
Family Brand Name:
Square D
Heights:
1-3/4 Inch
Material:
Metal
Number of Poles:
1 Pole
Size:
0.62 IN,1.56 IN,1.75-1.75 IN
Sub Brand:
9007MS/ML
Tc Connection:
PRE-WIRED CABLE BOTTOM
Type:
LIMIT SWITCH,PLUNGER HEAD
Voltage:
100 MA 125 Volt AC-30 MA 28 Volt DC
Widths:
1.56 in
SoneparProductId:
SKU_US_26283329
