Square-D / Schneider - Square D 9080LBA365112 600 Volt 380 Amp Power Distribution Block

12-Digit UPC:

785901097525

Amperage:

380-380 Amp COPPER-310-310 Amp ALUMINIUM

Applications:

9080LB,9080LB53

Catalog Number:

9080LBA365112

Conductor Size:

4 AWG-500 kcmil/14-2 AWG

Country of Origin:

USA

Current:

310 Amp

Depths:

3.13 Inch

ERP_productname:

SQD 9080LBA365112 PWR DIST BLOCK

Family Brand Name:

Square D

Heights:

5-1/2 Inch

Material:

Phenolic: Block

Mounting Type:

Surface Mount

Number of Poles:

3 Pole

Short Circuit Current:

65 kA

Short Circuit Current Ratng:

65 kA

Size:

3.13 in

Tc Connection:

LOAD LUG 50 LBF.IN AWG 3...AWG 2 COPPER OR ALUMINIUM-LOAD LUG 45 LBF.IN AWG 6...AWG 4 COPPER OR ALUMINIUM-LOAD LUG 40 LBF.IN AWG 8 COPPER OR ALUMINIUM-LOAD LUG 35 LBF.IN AWG 14...AWG 10 COPPER OR ALUMINIUM-LINE LUG 375 LBF.IN AWG 4...500 KCMIL COPPER OR ALUMINIUM,TIN PLATED ALUMINIUM LUGS

Type:

9080LB53;Power Distribution Block

Voltage:

600 Volt

Widths:

3.17 in

Wire Size:

Line 1, AWG 4...500 kcmil, copper or aluminium;Load 12, AWG 14...AWG 2, copper or aluminium

SoneparProductId:

SKU_US_25452935
