Square-D / Schneider - Square D 9080LBC162101 150 Amp 600 Volt 18 to 1/0 AWG Primary Phenolic 1-Pole Standard Power Distribution Block
Login or create an account to check prices & order
Essential specifications
12-Digit UPC - 785901097587
Amperage - 150-150 Amp COPPER
Applications - 9080LB,9080LB21
Catalog Number - 9080LBC162101
Conductor Size - 18-1/0 AWG
Packaging
1 ea
EAN
00785901097587
Part #
146444
Catalog #
9080LBC162101
Commercial reference
9080LBC162101
12-Digit UPC:
785901097587
Amperage:
150-150 Amp COPPER
Applications:
9080LB,9080LB21
Catalog Number:
9080LBC162101
Conductor Size:
18-1/0 AWG
Country of Origin:
USA
Current:
150 Amp
Depths:
1.78 Inch
ERP_productname:
SQD 9080LBC162101 PWR DISTR BLK 600V 150A
Family Brand Name:
Square D
Heights:
2.88 Inch
Material:
Phenolic: Block
Mounting Type:
Surface Mount
Number of Poles:
1 Pole
Short Circuit Current:
65 kA
Short Circuit Current Ratng:
65 kA
Size:
1.78 in
Tc Connection:
LINE LUG 50 LBF.IN AWG 6...AWG 1/0 COPPER-LINE LUG 40 LBF.IN AWG 8 COPPER-LINE LUG 35 LBF.IN AWG 14...AWG 10 COPPER-LOAD LUG 50 LBF.IN AWG 6...AWG 1/0 COPPER-LOAD LUG 40 LBF.IN AWG 8 COPPER-LOAD LUG 35 LBF.IN AWG 14...AWG 10 COPPER,TIN PLATED COPPER LUGS
Type:
9080LB21;Power Distribution Block
Voltage:
600 Volt
Widths:
1.13 in
Wire Size:
Line 1, AWG 18...AWG 1/0, copper;Load 1, AWG 18...AWG 1/0, copper
SoneparProductId:
SKU_US_26893598
