Square-D / Schneider - Square D 9080LBC163101 255 Amp 600 Volt 6 AWG to 250 kcmil Primary Phenolic 1-Pole Standard Power Distribution Block
Login or create an account to check prices & order
Essential specifications
12-Digit UPC - 785901097600
Amperage - 255-255 Amp COPPER
Applications - 9080LB,9080LB31
Catalog Number - 9080LBC163101
Conductor Size - 6 AWG-250 kcmil
Packaging
1 ea
EAN
00785901097600
Part #
146591
Catalog #
9080LBC163101
Commercial reference
9080LBC163101
12-Digit UPC:
785901097600
Amperage:
255-255 Amp COPPER
Applications:
9080LB,9080LB31
Catalog Number:
9080LBC163101
Conductor Size:
6 AWG-250 kcmil
Country of Origin:
USA
Current:
255 Amp
Depths:
2.61 Inch
ERP_productname:
SQD 9080LBC163101 PWR DISTR BLK 600V 255A
Family Brand Name:
Square D
Heights:
4 Inch
Material:
Phenolic
Mounting Type:
Surface Mount
Number of Poles:
1 Pole
Size:
1 1/2 in
Tc Connection:
LINE LUG 375 LBF.IN AWG 6...250 KCMIL COPPER OR ALUMINIUM-LOAD LUG 375 LBF.IN AWG 6...250 KCMIL COPPER OR ALUMINIUM,TIN PLATED COPPER LUGS
Type:
9080LB31;Power Distribution Block
Voltage:
600 Volt
Widths:
1.94 in
Wire Size:
Line 1, AWG 6...250 kcmil, copper;Load 1, AWG 6...250 kcmil, copper
SoneparProductId:
SKU_US_26412092
