Square-D / Schneider - Square D 9998LH55 277 Volt 60 Hz Contactor AC Coil
Login or create an account to check prices & order
Essential specifications
12-Digit UPC - 785901081180
Applications - CONTACTORS AND STARTERS, TYPE L/LX
Catalog Number - 9998LH55
Coil Voltage - 277 V
Country of Origin - Mexico
Packaging
1 ea
EAN
00785901081180
Part #
274550
Catalog #
9998LH55
Commercial reference
9998LH55
12-Digit UPC:
785901081180
Applications:
CONTACTORS AND STARTERS, TYPE L/LX
Catalog Number:
9998LH55
Coil Voltage:
277 V
Country of Origin:
Mexico
Depths:
37.1 mm
ERP_productname:
SQD 9998LH55 CONTACTOR, TYPE L, MULTIPOLE LIGHTING, REPLACEMENT COIL, 277 VAC 60 HZ, 8 TO 12 POLES
Family Brand Name:
Square D
Heights:
60.5 mm
Size:
1.46 in
Sub Brand:
SCHNEIDER ELECTRIC
Tc Connection:
SCREW CLAMP
Type:
Coil
Voltage:
277 Volt
Widths:
53.6 mm
SoneparProductId:
SKU_US_69990026
8903L multipole lighting contactors are for lighting control applications. Contactors can switch up to 30 A fluorescent and 20 A tungsten lighting loads. The coil can be easily replaced in a 8903 L lighting contactor. By changing out the coil, the lighting contactor can be used in different control circuit voltage applications. This will also save the cost of a whole new contactor if the coil were to fail. This coil is used in an 8903L, 8 to 12 poles, and 8930LX, 6 to 12 poles, lighting contactors. The coil is rated for 277 VAC 60 Hz. The inrush power of this coil is 180 VA. It has an average sealed consumption of 35 VA. This coil has a height of 2.38 inches, a width of 2.11 inches and a depth of 1.46 inches. Coil is fully encapsulated to protect it. Coil has screw clamp connections.
