Square-D / Schneider - Square D A250 2-1/2 Inch Bolt-On Mount Meter Socket Hub

Individual meter sockets have provisions to feed a downstream main lug load center, main breaker load center, or an individually enclosed service disconnect. Units can have a combination of releases, horn, or no bypasses to handle any meter socket situation. Units supplied with hub opening in top end wall require the use of a bolt-on hub or closing plate. This bolt on hub has a 2.50 inch conduit for use on enclosures that require A hubs. Hub is fastened to the enclosure with four 12-24 x 1/2 inch slotted hex washer head screws. This hub is rainproof and measures at 3.31 inches tall, 3.31 inches wide and 1.03 inches deep. Hub is UL Listed. Compatible Products: CM200S; CQRA200; EMT3225CB; QC12L200C; QC2442M200C; QC3040M200S; RC12L200C; RC1624M100S; RC200S; RC200SFMG; RC2040M150CH; RC2040M200C; RC2040M200CGP; RC2040M200CH; RC2040M200S; RC2M200S; RC3040M150SL; RC816F100CH; RC816F125CH; RC816F150C; RC816F150CH; RC816F200C; RC816F200CH; RC816F200S; RCM200SL; SC1624M100F; SC1624M100S; SC1624M125F; SC1624M125S; SC8L125S; SO1020M100S; SO1020VP; SO2040M200S; SO2040VP; UGHTRS213C; UHTRS101B; URS202BCR; UTRS101B; UTRS212C; UTRS213B; QC816F200C; SC2040M200C; SC2040M200PF; SC2040M200PS; SC3042M200PF; SC3042M200PS
