Square-D / Schneider - Square D CA2KN22U7 240 VAC 10 Amp 4.5 VA 4-Pole 2NO 2NC IEC Control Relay

CopyCopy
Square-D / Schneider - Square D CA2KN22U7 240 VAC 10 Amp 4.5 VA 4-Pole 2NO 2NC IEC Control Relay

Login or create an account to check prices & order

Essential specifications

  • 12-Digit UPC - 389110481375

  • Amperage - 10 Amp AT <= 50 ?.C

  • Applications - Control circuit

  • Catalog Number - CA2KN22U7

  • Country of Origin - Indonesia

Packaging

  • 1 ea

EAN

03389110481372

Part #

288852

Catalog #

CA2KN22U7

Commercial reference

CA2KN22U7

12-Digit UPC:

389110481375

Amperage:

10 Amp AT <= 50 ?.C

Applications:

Control circuit

Catalog Number:

CA2KN22U7

Country of Origin:

Indonesia

Depths:

57 mm

ERP_productname:

SQD CA2KN22U7 CONTROL RELAY, TESYS K, 2 NO + 2 NC, LT OR EQ TO 690V, 230 TO 240VAC COIL

Enclosure:

IP2X

Family Brand Name:

Schneider Electric

Heights:

58 mm

Size:

2.24 in

Sub Brand:

TESYS

Tc Connection:

SCREW CLAMP TERMINALS 1 1.5-4 MMA.SOLID- SCREW CLAMP TERMINALS 2 1.5-4 MMA.SOLID- SCREW CLAMP TERMINALS 1 0.75-4 MMA.FLEXIBLE WITH CABLE END- SCREW CLAMP TERMINALS 2 0.75-4 MMA.FLEXIBLE WITHOUT CABLE END- SCREW CLAMP TERMINALS 1 0.34-1.5 MMA.FLEXIBLE WITH CABLE END- SCREW CLAMP TERMINALS 2 0.34-1.5 MMA.FLEXIBLE WITHOUT CABLE END

Type:

Control relay

Voltage:

690 Volt

Widths:

45 mm

SoneparProductId:

SKU_US_25942486

TeSys K control relay, 4 contacts (2NO + 2NC), 10A/690V, for control of electromagnetic loads AC-15/DC-13. It provides a 230-240V 50/60Hz AC control circuit, connection by screw clamp terminals. For high operating rates until 180 cycles/min and ambient temperature -25/+50.C, it procures high reliability and durability. Compact (45mm width), for clipping on 35mm DIN rail or fixing by screw. Multi standards certified (IEC, UL, CSA, CCC, EAC), Green Premium product (RoHS/REACh). Prop 65: WARNING: This product can expose you to chemicals including: Antimony oxide & Antimony trioxide, which is known to the State of California to cause cancer. For more information go to www.P65Warnings.ca.gov - Compatible Products: LA1KN22; LA1KN40; LA4KA1U; LA1KN31; LA1KN04; LA4KE1UG; LA1KN13; LA9D90; LA2KT2U
