Square-D / Schneider - Square D CA2KN40U7 240 VAC 10 Amp 4.5 VA 4-Pole 4NO IEC Control Relay

Essential specifications

12-Digit UPC - 389110483379
Amperage - 10 Amp AT <= 50 .C
Applications - CONTROL CIRCUIT
Catalog Number - CA2KN40U7
Country of Origin - Indonesia

Packaging

1 ea

EAN

03389110483376

Part #

256052

Catalog #

CA2KN40U7

Commercial reference

CA2KN40U7

12-Digit UPC:

389110483379

Amperage:

10 Amp AT <= 50 .C

Applications:

CONTROL CIRCUIT

Catalog Number:

CA2KN40U7

Country of Origin:

Indonesia

Depths:

57 mm

ERP_productname:

SQD CA2KN40U7 CONTROL RELAY 600VAC

Enclosure:

IP2X

Family Brand Name:

Schneider Electric

Heights:

58 mm

Size:

45 MM,57 MM,58 MM

Sub Brand:

CA2K,TESYS CAK

Tc Connection:

SCREW CLAMP TERMINALS 1 1.5-4 MMA.SOLID- SCREW CLAMP TERMINALS 2 1.5-4 MMA.SOLID- SCREW CLAMP TERMINALS 1 0.75-4 MMA.FLEXIBLE WITH CABLE END- SCREW CLAMP TERMINALS 2 0.75-4 MMA.FLEXIBLE WITHOUT CABLE END- SCREW CLAMP TERMINALS 1 0.34-1.5 MMA.FLEXIBLE WITH CABLE END- SCREW CLAMP TERMINALS 2 0.34-1.5 MMA.FLEXIBLE WITHOUT CABLE END

Type:

CONTROL RELAY

Voltage:

690 Volt

Widths:

45 mm

SoneparProductId:

SKU_US_26066084

TeSys K control relay, 4 contacts (4NO), 10A/690V, for control of electromagnetic loads AC-15/DC-13. It provides a 230-240V 50/60Hz AC control circuit, connection by screw clamp terminals. For high operating rates until 180 cycles/min and ambient temperature -25/+50.C, it procures high reliability and durability. Compact (45mm width), for clipping on 35mm DIN rail or fixing by screw. Multi standards certified (IEC, UL, CSA, CCC, EAC), Green Premium product (RoHS/REACh). Prop 65: WARNING: This product can expose you to chemicals including: Antimony oxide & Antimony trioxide, which is known to the State of California to cause cancer. For more information go to www.P65Warnings.ca.gov - Compatible Products: LA1KN22; LA1KN40; LA4KA1U; LA1KN31; LA1KN04; LA4KE1UG; LA1KN13; LA9D90; LA2KT2U
