Square-D / Schneider - Square D GB2CB09 1-Pole 4 Amp 300 VAC Thermal Magnetic Circuit Protector
Login or create an account to check prices & order
Essential specifications
12-Digit UPC - 389110214683
Amperage - 4 Amp
Applications - Control
Catalog Number - GB2CB09
Country of Origin - France
Packaging
1 ea
EAN
03389110214680
Part #
224020
Catalog #
GB2CB09
Commercial reference
GB2CB09
12-Digit UPC:
389110214683
Amperage:
4 Amp
Applications:
Control
Catalog Number:
GB2CB09
Country of Origin:
France
Depths:
67 mm
ERP_productname:
SQD GB2CB09 4.0A CIRCUIT PROTECTOR
Enclosure:
IP20 CONFORMING TO IEC 60529
Family Brand Name:
Schneider Electric
Heights:
74 mm
Mounting Type:
Clips
Sub Brand:
TESYS
Type:
Circuit breaker
Voltage:
250 Volt
Widths:
15 mm
SoneparProductId:
SKU_US_26591727
TeSys GB circuit breaker, 1 pole (1P), 4A/250V IEC/277V UL, for the protection of industrial equipment control circuits. It provides thermal-magnetic protection with a magnetic tripping level at 52A (13 In) and breaking capacity Icu 3kA@240V. It can also be used for protection of DC loads up to 4A/48V DC-13 with a breaking capacity Icu 1.5kA@24V. Compact device (15mm wide), mounting on 35mm DIN-rail, control by toggle lever (start-stop guaranteed for 8000 cycles). Sold in lots of 6 units. Multi standards certified (IEC, UL, CSA), Green Premium product (RoHS/REACh). Prop 65: WARNING: Cancer - www.P65Warnings.ca.gov
