Square-D / Schneider - Square D LA1DX02 AUX. CONTACT IEC

Essential specifications

12-Digit UPC - 785901598572
Applications - LA1
Catalog Number - LA1DX02
Coil Voltage - <= 50 V
Country of Origin - France

Packaging

1 ea

EAN

03389110970616

Part #

113948

Catalog #

LA1DX02

Commercial reference

LA1DX02

12-Digit UPC:

785901598572

Applications:

LA1

Catalog Number:

LA1DX02

Coil Voltage:

<= 50 V

Country of Origin:

France

Depths:

39 mm

ERP_productname:

SQD LA1DX02 AUX. CONTACT IEC

Family Brand Name:

Schneider Electric

Heights:

48 mm

Size:

1.54 in

Sub Brand:

TeSys D

Tc Connection:

SCREW CLAMP TERMINALS 1 1-2.5 MMA.FLEXIBLE WITH CABLE END- SCREW CLAMP TERMINALS 1 1-2.5 MMA.FLEXIBLE WITHOUT CABLE END- SCREW CLAMP TERMINALS 2 1-2.5 MMA.FLEXIBLE WITH CABLE END- SCREW CLAMP TERMINALS 2 1-2.5 MMA.FLEXIBLE WITHOUT CABLE END- SCREW CLAMP TERMINALS 1 1-2.5 MMA.SOLID- SCREW CLAMP TERMINALS 2 1-2.5 MMA.SOLID

Type:

Auxiliary contact block

Voltage:

125 Volt

Widths:

44 mm

SoneparProductId:

SKU_US_29027513

LA1DX02 is a Schneider Electric instantaneous auxiliary contact block for TeSys D contactors. It provides 2NC dust and damp protected contacts rated up to 125V AC and 30V DC, connection by screw clamp terminals. Easy clip-on mounting on front, it procures high reliability and durability. Available worldwide, it is multi-standards certified (IEC, UL, CSA, CCC) and Green Premium compliant (RoHs/Reach). Multi standards certified (IEC, UL, CSA, CCC, EAC), Green Premium compliant (RoHS/REACh). Compatible Products: CAD32BD; CAD32M7; CAD32P7; CAD32F7; CAD32E7; CAD50BD; CAD32FD; CAD50F7; CAD50P7; CAD32B7; CAD50M7; CAD32G7; CAD32MD; CAD32V7; CAD32GD; CAD50E7; CAD32U7; CAD50B7; CAD32T7; CAD50G7; CAD32FE7; CAD50FD; CAD32ED; CAD32Q7; CAD50GD; CAD32D7; CAD32JD; CAD50U7; CAD32G7TQ; CAD32X7; CAD32UD; CAD50ED; CAD32SD; CAD32L7; CAD50SD; CAD32FC7; CAD50L7; CAD50UD; CAD32C7 - Cross Sell Products: LRD08
