Square-D / Schneider - Square D LC1K09008M7 CONTACTOR 600VAC 9AMP IEC +OPTIONS

Essential specifications

12-Digit UPC - 389110488879
Applications - CONTROL,RESISTIVE LOAD
Catalog Number - LC1K09008M7
Coil Voltage - 220...230 V AC 50/60 HZ,POWER CIRCUIT 690 V AC 50/60 HZ
Country of Origin - Indonesia

Packaging

1 ea

EAN

03389110488876

Part #

152793

Catalog #

LC1K09008M7

Commercial reference

LC1K09008M7

12-Digit UPC:

389110488879

Applications:

CONTROL,RESISTIVE LOAD

Catalog Number:

LC1K09008M7

Coil Voltage:

220...230 V AC 50/60 HZ,POWER CIRCUIT 690 V AC 50/60 HZ

Country of Origin:

Indonesia

Depths:

57 mm

ERP_productname:

SQD LC1K09008M7 CONTACTOR 600VAC 9AMP IEC

Family Brand Name:

Schneider Electric

Heights:

58 mm

Impedance:

3 MOhm - Ith 20 A 50 Hz For Power Circuit

Size:

57 MM

Sub Brand:

TESYS K

Tc Connection:

SCREW CLAMP TERMINALS 1 1.5-4 MMA.SOLID- SCREW CLAMP TERMINALS 1 0.75-4 MMA.FLEXIBLE WITHOUT CABLE END- SCREW CLAMP TERMINALS 1 0.34-2.5 MMA.FLEXIBLE WITH CABLE END- SCREW CLAMP TERMINALS 2 1.5-4 MMA.SOLID- SCREW CLAMP TERMINALS 2 0.75-4 MMA.FLEXIBLE WITHOUT CABLE END- SCREW CLAMP TERMINALS 2 0.34-1.5 MMA.FLEXIBLE WITH CABLE END

Type:

Contactor

Voltage:

690 Volt

Widths:

45 mm

SoneparProductId:

SKU_US_29015312

TeSys K contactor, 4 poles (2NO+2NC), for non-inductive load control applications up to 20A/690V AC-1. It provides a 220V 50/60Hz AC coil, without built-in auxiliary contact, connection by screw clamp terminals. For operating rates until 600 cycles/hour and environments until 50.C, it procures reliability and durability to standard applications. Very compact (45mm width), DIN-rail mounting or screw fixing. Multi standards certified (IEC, UL, CSA, CCC, EAC), Green Premium compliant (RoHS/REACh). Prop 65: WARNING: This product can expose you to chemicals including: Antimony oxide & Antimony trioxide, which is known to the State of California to cause cancer. For more information go to www.P65Warnings.ca.gov - Compatible Products: LA1KN22; LA1KN11; LA1KN40; LA4KA1U; LA1KN31; LA1KN20; LA1KN04; LA4KE1UG; LA1KN02; LA1KN13; LA9D90; LA2KT2E; LA2KT2U
