Square-D / Schneider - Square D LC1K1210L7 Contactor, TeSys K, 3P, AC-3, Less or Equal to 440V 12 A, 1 NO Aux., 200 to 208VAC Coil

Essential specifications

12-Digit UPC - 785901297888
Applications - CONTROL,MOTOR CONTROL-RESISTIVE LOAD
Catalog Number - LC1K1210L7
Coil Voltage - 200...208 V AC 50/60 HZ,POWER CIRCUIT 690 V AC 50/60 HZ-SIGNALLING CIRCUIT <= 690 V AC 50/60 HZ
Country of Origin - France

Packaging

1 ea

EAN

03389118049833

Part #

165019

Catalog #

LC1K1210L7

Commercial reference

LC1K1210L7

12-Digit UPC:

785901297888

Applications:

CONTROL,MOTOR CONTROL-RESISTIVE LOAD

Catalog Number:

LC1K1210L7

Coil Voltage:

200...208 V AC 50/60 HZ,POWER CIRCUIT 690 V AC 50/60 HZ-SIGNALLING CIRCUIT <= 690 V AC 50/60 HZ

Country of Origin:

France

Depths:

57 mm

ERP_productname:

SQD LC1K1210L7 CONTACTOR 600VAC 12AMP IEC +OPTIONS

Family Brand Name:

Schneider Electric

Heights:

58 mm

Impedance:

3 MOhm - Ith 20 A 50 Hz For Power Circuit

Size:

45 MM,57 MM,58 MM

Sub Brand:

TESYS K

Tc Connection:

SCREW CLAMP TERMINALS 1 1.5-4 MMA.SOLID- SCREW CLAMP TERMINALS 1 0.75-4 MMA.FLEXIBLE WITHOUT CABLE END- SCREW CLAMP TERMINALS 1 0.34-2.5 MMA.FLEXIBLE WITH CABLE END- SCREW CLAMP TERMINALS 2 1.5-4 MMA.SOLID- SCREW CLAMP TERMINALS 2 0.75-4 MMA.FLEXIBLE WITHOUT CABLE END- SCREW CLAMP TERMINALS 2 0.34-1.5 MMA.FLEXIBLE WITH CABLE END

Type:

CONTACTOR

Voltage:

690 Volt

Widths:

45 mm

SoneparProductId:

SKU_US_29105718

TeSys K contactor, 3 poles (3NO), for motor control applications up to 12A/690V AC-3 (5.5kW@400V), and for non-inductive load control applications up to 20A/690V AC-1. It provides a 200-208V 50/60Hz AC coil, 1NO built-in auxiliary contact, connection by screw clamp terminals. For operating rates until 600 cycles/hour and environments until 50.C, it procures reliability and durability to standard applications. Very compact (45mm width), DIN-rail mounting or screw fixing. Multi standards certified (IEC, UL, CSA, CCC, EAC), Green Premium compliant (RoHS/REACh). Prop 65: WARNING: This product can expose you to chemicals including: Antimony oxide & Antimony trioxide, which is known to the State of California to cause cancer. For more information go to www.P65Warnings.ca.gov - Compatible Products: LA1KN22; LA1KN11; LA1KN40; LA4KA1U; LA1KN31; LA1KN20; LA1KN04; LA4KE1UG; LA1KN02; LA1KN13; LA9D90; LA1KN22M; LA1KN11M; LA2KT2E; LA2KT2U - Cross Sell Products: GV2ME16; GV2LE16; LR2K0321
