Square-D / Schneider - Square D QHB215 Miniature Circuit Breaker 15A 120/240V 2P , Thermal Magnetic

QO and QOB one, two and three pole thermal magnetic circuit breakers provide overcurrent protection and switching on ac and dc systems. These circuit breakers have an over center, trip free toggle mechanism with quick make, quick break action and positive handle indication. They also have VisiTrip trip indication, which provides a visual indication that the circuit breaker has tripped and interrupted the circuit. This 2 pole QO circuit breaker is rated at 15A at 120/240VAC. This unit provides 65kA breaking capacity and bolt on mounting. A full line of features and factory installed accessories are also available such as shunt trips, auxiliary switches and alarm switches. QO circuit breakers are UL Listed under UL File E84967 and are CSA Certified under CSA Master Contract 153555. A full line of factory installed accessories are available. The pressure plate connectors will accept one 14 AWG to 8 AWG copper or aluminum wire. This circuit breaker has a height of 3.00 inches, a width of 1.50 inches and a depth of 2.91 inches. This QHB circuit breaker is UL Listed and CSA Certified. Compatible Products: HLO1; QO142M200P; QO142L225PG; QO3HT; QO1HPL; QO1PL; QO342MQ200; QO2DTI; QO1816M200FTRB; QO2DTIM; QO130L200PG; QO2PAF; QO816L100RB; QO342L225G; QO24L70RB; QO324L125G
