Square-D / Schneider - Square D S33930 1200 Amp 3/0 AWG to 600 MCM Copper/Aluminum Sub-Feed Lug Kit
Login or create an account to check prices & order
Essential specifications
12-Digit UPC - 785901231967
Amperage - 1200 Amp
Applications - P-frame
Catalog Number - S33930
Circuit Breaker Type - P-Frame
Packaging
1 ea
EAN
00785901231967
Part #
123659
Catalog #
S33930
Commercial reference
S33930
12-Digit UPC:
785901231967
Amperage:
1200 Amp
Applications:
P-frame
Catalog Number:
S33930
Circuit Breaker Type:
P-Frame
Country of Origin:
USA
ERP_productname:
SQD S33930 CIRCUIT BREAKER SUBFEED LUG KIT
Family Brand Name:
Square D
Length:
381 mm
Sub Brand:
I-LINE
Tc Connection:
AWG 3/0...600 KCMIL
Type:
Sub-feed lug
SoneparProductId:
SKU_US_31176880
Square D sub-feed lug kits are UL Listed for use on Listed equipment. They have plug-on jaw construction and plug on to the I-Line bus stack in the same manner as branch circuit breakers. Lugs on these devices accommodate the same wire sizes as the equivalent ampere rated circuit breakers. This I-line sub-feed lug kit is 3 pole with 1200A current rating and is used for I-line, HCR-U panels with I-line circuit breakers. Mounting height is 15 inches and terminal data is 4 wires of AWG 3/0 - 600 kcmil. There are 4 conducters per lug. Prop 65: WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov - Compatible Products: HC3248B; HC3264B; HC3273B; HC3273DB9; HC3291B; HC3291DB9; HC4250DB; HC4250WP; HC4259DB; HC4259WP; HC4268DB; HC4286DB; HC4486DB
