Square-D / Schneider - Square D VZ1 690 VAC 32 Amp 1NO Add-On Contact Module

Essential specifications

12-Digit UPC - 389110551863
Amperage - 32 Amp
Applications - TESYS VARIO SWITCH DISCONNECTOR,V1
Catalog Number - VZ1
Country of Origin - Czechia

Packaging

1 ea

EAN

03389110551860

Part #

227536

Catalog #

VZ1

Commercial reference

VZ1

12-Digit UPC:

389110551863

Amperage:

32 Amp

Applications:

TESYS VARIO SWITCH DISCONNECTOR,V1

Catalog Number:

VZ1

Country of Origin:

Czechia

Depths:

35 mm

ERP_productname:

SQD VZ1 POWER POLE

Enclosure:

IP20 CONFORMING TO IEC 60529

Family Brand Name:

Schneider Electric

Heights:

74 mm

Number of Poles:

1 Pole

Size:

16 MM,35 MM,74 MM

Sub Brand:

Tc Connection:

POWER CIRCUIT SCREW CLAMP TERMINALS 6-6 MMA. FLEXIBLE - WITH CABLE END-POWER CIRCUIT SCREW CLAMP TERMINALS 10-10 MMA. SOLID

Type:

ADDITIONAL POLE

Voltage:

690 Volt

Widths:

16 mm

SoneparProductId:

SKU_US_26609093

VZ1 is an add-on main pole module for TeSys Vario switch-disconnector from Schneider Electric. It is rated 32A 690V, compatible with switch types V1. VZ1 is an add-on main pole module for TeSys Vario switch-disconnector from Schneider Electric. It is rated 32A 690V, compatible with switch types V1. A maximum of 3 VZ1 main pole modules can be attached to a switch body V1. Available worldwide, it is multi-standards certified (IEC, UL, CSA, CCC, EAC) and Green Premium compliant (RoHs/Reach). Add-on main pole module for Vario switch disconnector assemblies. Same AC and DC ratings as V1 switch bodies. Other add-on modules available for V1 switch bodies , neutral (VZ11), earthing (VZ14), auxiliary contacts (VZ7, VZ20). Compatible Products: VCF1; VZ26; VCCF1; VCF1GE; VCD1; VC1GUN; VCCD1; VVD1; VVE1 - Cross Sell Products: V1; VBF1; VBF1GE; VBD1
