Square-D / Schneider - Square D XENB1181 40 mm 240 VAC 3 Amp 2NO Spring Return Pendant Station Contact

12-Digit UPC:

389110607652

Amperage:

10 Amp

Applications:

Control circuit;2-speed;XACB;XACM

Catalog Number:

XENB1181

Country of Origin:

Czechia

ERP_productname:

SQD XENB1181 PENDANT STATION CONTACT 240VAC 3A XAC

Family Brand Name:

Schneider Electric

Sub Brand:

XENB

Tc Connection:

SCREW CLAMP TERMINALS, 1 X 2.5 MMA. WITH OR WITHOUT CABLE END-SCREW CLAMP TERMINALS, 2 X 1.5 MMA. WITH OR WITHOUT CABLE END

Type:

Single;Contact block;Spring return

Wattage:

31 Watt DC-13 1000000 CYCLES 60 CYC/MN 48 Volt 0.5 INDUCTIVE IEC 60947 - 5-1 APPENDIX C-35 Watt DC-13 1000000 CYCLES 60 CYC/MN 120 Volt 0.5 INDUCTIVE IEC 60947 - 5-1 APPENDIX C-48 Watt DC-13 1000000 CYCLES 60 CYC/MN 24 Volt 0.5 INDUCTIVE IEC 60947 - 5-1 APPENDIX C

SoneparProductId:

SKU_US_26322407
