Square-D / Schneider - SQUARED M9L23240 surge arrester, Mu

CopyCopy
Square-D / Schneider - SQUARED M9L23240 surge arrester, Mu

Login or create an account to check prices & order

Essential specifications

  • 12-Digit UPC - 606481585922

  • Catalog Number - M9L23240

  • Color - Gray RAL 7035)

  • Country of Origin - France

  • Depths - 71.4 mm

Packaging

  • 1 ea

EAN

03606481585929

Part #

490402

Catalog #

M9L23240

Commercial reference

M9L23240

12-Digit UPC:

606481585922

Catalog Number:

M9L23240

Color:

Gray RAL 7035)

Country of Origin:

France

Depths:

71.4 mm

ERP_productname:

SQD M9L23240 SURGE ARRESTER, MULTI9 PRD1 75R, 3P, 240 V

Family Brand Name:

Schneider Electric

Heights:

91.7 mm

Mounting Type:

Clip-On

Widths:

52.5 mm

SoneparProductId:

SKU_US_226449171

This Multi9 PRD1 product is a surge arrester. it can be installed in a variety of installations including service entrance, branch panels and control panel environments. It is connected to electrical distribution network. Its surge arrester class type is type 1. The Imax maximum discharge current is 75kA. It can be associated with a 30A and C curve tripping circuit breaker. The Uc maximum continuous operating voltage is 275VAC in common mode (L/N). The In nominal discharge current is 20kA (L/PE). The Up maximum voltage protection level is 900V (L/N) and 1800V (L/L). It can be mounted on DIN rail for modular installation. Its width is 6 pitches of 9mm. The degree of protection is NEMA 1. The operating temperature is -25.C to 60.C. The storage temperature is -40.C to 85.C. This product complies with UL 1449 standard. Prop 65: WARNING: This product can expose you to chemicals including: DINP, which is known to the State of California to cause cancer, and DIDP, which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov - Spare Part Products: M9LC275
