Square-D / Schneider - SQUARED RPM41FD Power plug in relay
Login or create an account to check prices & order
Essential specifications
12-Digit UPC - 389119402173
Amperage - 15 Amp
Catalog Number - RPM41FD
Country of Origin - China
ERP_productname - SQD RPM41FD PLUG-IN RELAY 250V 15A RPM +OPTIONS
Packaging
1 ea
EAN
03389119402170
Part #
147897
Catalog #
RPM41FD
Commercial reference
RPM41FD
12-Digit UPC:
389119402173
Amperage:
15 Amp
Catalog Number:
RPM41FD
Country of Origin:
China
ERP_productname:
SQD RPM41FD PLUG-IN RELAY 250V 15A RPM +OPTIONS
Enclosure:
IP 40 CONFORMING TO IEC/EN 60529
Family Brand Name:
Schneider Electric
Sub Brand:
RPM
Tc Connection:
FLAT/SPADE (FASTON TYPE)
Type:
Plug-in relay;Flat
SoneparProductId:
SKU_US_29349392
This Harmony RPM power plug-in relay has a coil control voltage of 110V DC and has 4 changeover contacts 4PDT (quadruple pole double throw) with a rating of 15A. It has large choice of number of contacts for high rated current use. It helps to reduce the size of enclosures and increases machine reliability, you can mount nearly everywhere. Plug in type enables easy installation and maintenance. Workability for hard-wired logic automated systems to complement the functions of industrial programmable logic controllers (PLCs). 0 0 0 0 0 0 0 0 0 0 0 0 0 0
