Square-D / Schneider - SQUARED VLS1P040R1S Disconnect swit
Login or create an account to check prices & order
Essential specifications
12-Digit UPC - 606481156597
Amperage - 40 Amp AC-21A UE: 400 V-40 Amp UE: 600 V UL 508-40 Amp AC-21A UE: 500 V-40 Amp AC-21A UE: 690 V-40 Amp AC-22A UE: 400 V-40 Amp AC-22A UE: 500 V-40 Amp AC-22A UE: 690 V-40 Amp AC-23A UE: 400 V-25 Amp AC-23A UE: 500 V-25 Amp AC-23A UE: 690 V
Applications - TESYS VARIO LS VLS3P
Catalog Number - VLS1P040R1S
Color - Gray
Packaging
1 ea
EAN
03606481156594
Part #
184340
Catalog #
VLS1P040R1S
Commercial reference
VLS1P040R1S
12-Digit UPC:
606481156597
Amperage:
40 Amp AC-21A UE: 400 V-40 Amp UE: 600 V UL 508-40 Amp AC-21A UE: 500 V-40 Amp AC-21A UE: 690 V-40 Amp AC-22A UE: 400 V-40 Amp AC-22A UE: 500 V-40 Amp AC-22A UE: 690 V-40 Amp AC-23A UE: 400 V-25 Amp AC-23A UE: 500 V-25 Amp AC-23A UE: 690 V
Applications:
TESYS VARIO LS VLS3P
Catalog Number:
VLS1P040R1S
Color:
Gray
Country of Origin:
Italy
Depths:
43.6 mm
ERP_productname:
SQD VLS1P040R1S 4TH POLE 40A FOR VLS3P040R1
Family Brand Name:
Schneider Electric
Heights:
78 mm
Interrupt Rating:
60, 120, 320 AIC
Number of Poles:
1 Pole
Size:
1.72 in
Sub Brand:
VLS1P
Tc Connection:
POWER CIRCUIT SCREW CLAMP TERMINALS 10-10 MMA. SOLID-POWER CIRCUIT SCREW CLAMP TERMINALS 16-16 MMA. FLEXIBLE - WITHOUT CABLE END
Type:
Additional pole
Voltage:
690 Volt
Wattage:
18.5 kW 400 Volt AC-23 Amps)-18.5 kW 500 Volt AC-23 Amps)-22 kW 690 Volt AC-23 Amps)
Widths:
12 mm
SoneparProductId:
SKU_US_25434924
