TESENSOR - SQUARED XUAH0515 Photoelectric sens

Essential specifications

12-Digit UPC - 389110427168
Amperage - <= 100 MA OVERLOAD AND SHORT-CIRCUIT PROTECTION)
Applications - -
Catalog Number - XUAH0515
Country of Origin - France

Packaging

1 ea

EAN

03389110427165

Part #

214930

Catalog #

XUAH0515

Commercial reference

XUAH0515

12-Digit UPC:

389110427168

Amperage:

<= 100 MA OVERLOAD AND SHORT-CIRCUIT PROTECTION)

Applications:

Catalog Number:

XUAH0515

Country of Origin:

France

Current:

25 mA

ERP_productname:

TES XUAH0515 PHOTOELECTRIC SENSOR 24V 100MA +OPTIONS

Enclosure:

IP65 CONFORMING TO IEC 60529,NICKEL PLATED BRASS

Enclosure Material:

Brass

Family Brand Name:

Telemecanique

Length:

47 mm

Material:

Metal

Sensing Range:

0.05-0.05 M DIFFUSE,> 0...0.98 FT (> 0...0.3 M)

Size:

0.31 in

Sub Brand:

OSISENSE

Tc Connection:

CABLE

Type:

Diffuse;Photo-electric sensor;Cylindrical M8;Application assembly

Voltage:

12...24 Volt DC REVERSE POLARITY PROTECTION

SoneparProductId:

SKU_US_73690011

This product is part of the XU range, an offer of photoelectric sensors. This photoelectric sensor in XUA cylindrical M18 design. It has a diffuse detection system. It supports nominal sensing distance of 0.05m diffuse with 1 normally opened discrete type of output signal. It is furnished with 2m cable for electrical connection. This photoelectric sensor, with infrared diffuse emission, has 1 LED for output state. It is an IP65 rated product. It is a photoelectric sensor with a rated supply voltage of 12V to 24V DC with reverse polarity protection, a no-load current consumption of ?25mA and a switching frequency of ?1000Hz. The enclosure is made of nickel plated brass with PMMA lens. Its dimensions are 8mm (Diameter) x 47mm (Length) and weighs 0.015kg. It is ideal for material handling, packaging, labelling, assembly, lift, escalators or food and beverage industries. This product is certified by CE and CULus.
