TESENSOR - TEC XUK2LAPSMM12R Photoelectric sensors XU, photo electric laser sensor, XUK, thru beam receiver, Sn 30 m, 10...30 VDC, M12

This product is part of the XU range, an offer of photoelectric sensors. This photoelectric sensor has a compact 50mm x 50mm design with thru beam detection system. It supports 25m nominal sensing distance and 1 NO or 1 NC programmable PNP discrete output. The photoelectric sensor with a rated supply voltage of 12V to 24V DC with reverse polarity protection and no load current consumption of ?10mA. It is furnished with 4-pin M12 male connector for electrical connection. It is an IP67/IP69K rated product. The enclosure is made of ABS/PC with PMMA lens. Its dimensions are 23mm (width) x 50mm (depth) x 50mm (height). It weighs 0.035kg. Ideal for material handling, packaging, labelling, assembly, lift, escalators or food and beverage industries. This product is certified by CE, CULus and Ecolab. The XU is for non contact sensing up to a hundred meters of objects of any shape and any type. The XU range offers a full line of photoelectric proximity sensors dedicated to material handling, packaging, labelling, lift, food and beverage industries.
