TESENSOR - TES XSDC607139 Inductive proximity sensors XS, inductive sensor XSD 80x80x40, plastic, Sn60mm, 12...48 VDC, terminals
Login or create an account to check prices & order
Essential specifications
12-Digit UPC - 785901236610
Applications - -
Catalog Number - XSDC607139
Depths - 40 mm
ERP_productname - TES XSDC607139 INDUCTIVE SENSOR 48VDC 100MA XS-(METRIC)
Packaging
1 ea
EAN
03389110619744
Part #
220504
Catalog #
XSDC607139
Commercial reference
XSDC607139
12-Digit UPC:
785901236610
Applications:
-
Catalog Number:
XSDC607139
Depths:
40 mm
ERP_productname:
TES XSDC607139 INDUCTIVE SENSOR 48VDC 100MA XS-(METRIC)
Enclosure:
Plastic
Enclosure Material:
Plastic
Family Brand Name:
Telemecanique
Heights:
100 mm
Material:
Plastic
Sensing Range:
> 1.57...2.36 IN (> 40...60 MM)
Size:
40 mm
Sub Brand:
XSD
Type:
Form 80 x 80 x 40;Inductive proximity sensor
Widths:
80 mm
SoneparProductId:
SKU_US_26322446
The XS range is an offer of inductive proximity sensors for the detection, without physical contact, of metal objects. The advantages of inductive detection are numerous, no physical contact with the object to be detected. Thus avoiding wear and enabling detection of fragile or freshly painted objects. High operating rates. Fast response. Excellent resistance to industrial environments (robust products, fully encapsulated in resin). This product is a flat format, 80mm x 80mm x 40mm, non flush mountable sensor. It features a plastic case and a PG 13.5 cable entry. It has a sensing distance of 60mm. Two-wire, DC supply, 12V to 48V, NO function.
