Thomas & Betts Co - ABB CTL3502 CU TP 2HL LUG SHRT BRL
Login or create an account to check prices & order
Essential specifications
12-Digit UPC - 783786131983
Applications - For Medium Voltage Applications
Catalog Number - CTL3502
Color - Red
Conductor Size - 350 kcmil
Packaging
1 ea
EAN
00783786131983
Part #
303156
Catalog #
CTL3502
Commercial reference
CTL3502
12-Digit UPC:
783786131983
Applications:
For Medium Voltage Applications
Catalog Number:
CTL3502
Color:
Red
Conductor Size:
350 kcmil
ERP_productname:
CARB CTL3502 CU TP 2HL LUG SHRT BRL 350 1/2B RED
Family Brand Name:
Thomas & Betts (T&B)
Finish:
Tin Plated
Material:
Copper
Number of Holes:
2 Hole
Sub Brand:
Blackburn®
Type:
Standard Barrel
Voltage:
35 kV
Wire Size:
350 kcmil
SoneparProductId:
SKU_US_73744185
Type CTL Copper Two-Hole Lug, Short Barrel, Max 35kV, Wire Size 350 kcmil, 1/2 Inch Bolt Size, Tin Plated, Die Color Code Red Features: Complies with Subpart 111.60-17 of Federal Register's Coast Guard Electrical Engineering Rules and Regulations.; UL Listed for AWG conductor when installed with Blackburn, Burndy, T&B or Andersons Tools.; Specifically chamfered barrel for ease of installation.; Made of high-conductivity seamless copper tubing. Tin plated for corrosion resistance.; Color-coded for matching die identification. - Notes: For use with copper conductor: AWG, stranded, flexible cable, welding cable and portable cord. Specially designed for inductrial and building applications.
