Thomas & Betts Co - Blackburn ADR25-32 Extruded Aluminum Lug
Login or create an account to check prices & order
Essential specifications
12-Digit UPC - 783786610136
Catalog Number - ADR25-32
Conductor Size - 6 AWG-250 kcmil
ERP_productname - BLKB ADR25-32 EXTR ALUM LUG
Family Brand Name - ABB
Packaging
1 ea
EAN
00783786610136
Part #
213585
Catalog #
ADR25-32
Commercial reference
ADR25-32
12-Digit UPC:
783786610136
Catalog Number:
ADR25-32
Conductor Size:
6 AWG-250 kcmil
ERP_productname:
BLKB ADR25-32 EXTR ALUM LUG
Family Brand Name:
ABB
Finish:
Tin Plated
Length:
4-3/16 Inch
Material:
Aluminum
Number of Conductors:
3
Sub Brand:
Blackburn®
Type:
Dual-Rated
SoneparProductId:
SKU_US_58943043
Type ADR-ALCUL Three-Conductor, Two-Hole Mount for Conductor Range Max 250 kcmil, Min 6 Str. Certifications: CSA; UL - Notes: Connectors accomodating conductors 600 kcmil and larger have double rows of set screws (D suffix).; UL 486B tested, AL9CU rated; NEMA spacing 1 3/4 inch centers. - Features: Easy Installation - no special tools required.
