Thomas & Betts Co - Blackburn ATL20-38 Aluminum Compression Lug
Login or create an account to check prices & order
Essential specifications
12-Digit UPC - 783786610976
Applications - For Aluminum and Copper Conductor
Catalog Number - ATL20-38
Color - Olive
Conductor Size - 2/0 AWG
Packaging
1 ea
EAN
05415022239607
Part #
112281
Catalog #
ATL20-38
Commercial reference
ATL20-38
12-Digit UPC:
783786610976
Applications:
For Aluminum and Copper Conductor
Catalog Number:
ATL20-38
Color:
Olive
Conductor Size:
2/0 AWG
ERP_productname:
BLKB ATL20-38 2/0 AL TP COMP LUG 1HL 3/8IN OLV
Family Brand Name:
Thomas & Betts (T&B)
Finish:
Tin Plated
Heights:
2.3 Inch
Material:
Aluminum
Number of Holes:
1 Hole
Sub Brand:
Blackburn®
Type:
Round/Sector Shaped
Voltage:
35 Volt
Widths:
2.8 in
SoneparProductId:
SKU_US_58943197
Type ATL Aluminum One-Hole Lug, Max 35kV, Wire Size 2/0 Str, 3/8 Inch Bolt Hole, Tin Plated, Die Color Code Olive Features: UL Listed when installed with Blackburn, Burndy, T&B or Andersons Tools.; Made of high-conductivity seamless aluminum tubing. Tin plated for corrosion resistance.; Color-coded for matching die identification. Prefilled with oxide inhibiting compound.; Specifically chamfered barrel for ease of installation. - Certifications: UL; CSA - Notes: For use with aluminum conductor (concentric, compressed or compact). Also listed for use with copper conductor.
