Thomas & Betts Co - Blackburn ATL40-12 Aluminum Compression Lug
Login or create an account to check prices & order
Essential specifications
12-Digit UPC - 783786611003
Applications - For Medium Voltage Applications
Catalog Number - ATL40-12
Color - White
Conductor Size - 4/0 AWG
Packaging
1 ea
EAN
05415022239683
Part #
112293
Catalog #
ATL40-12
Commercial reference
ATL40-12
12-Digit UPC:
783786611003
Applications:
For Medium Voltage Applications
Catalog Number:
ATL40-12
Color:
White
Conductor Size:
4/0 AWG
ERP_productname:
BLKB ATL40-12 4/0 AL TP COMP LUG 1HL 5/16IN WHT
Family Brand Name:
Thomas & Betts (T&B)
Finish:
Tin Plated
Heights:
3 Inch
Material:
Aluminum
Number of Holes:
1 Hole
Sub Brand:
Blackburn®
Type:
Aluminum One-Hole Lug
Voltage:
35 Volt
Widths:
4 in
SoneparProductId:
SKU_US_59363624
Type Aluminum One-Hole Lug, Max 35kV, Wire Size 4/0 Str, 1/2 Inch Bolt Hole, Tin Plated, Die Color Code White Features: UL Listed when installed with Blackburn, Burndy, T&B or Andersons Tools.; Color-coded for matching die identification. Prefilled with oxide inhibiting compound.; Made of high-conductivity seamless aluminum tubing. Tin plated for corrosion resistance.; Specifically chamfered barrel for ease of installation. - Certifications: UL; CSA - Notes: For use with aluminum conductor (concentric, compressed or compact). Also listed for use with copper conductor.
