Thomas & Betts Co - Blackburn CF22-1 Compression Connector
Login or create an account to check prices & order
Essential specifications
12-Digit UPC - 783786092215
Catalog Number - CF22-1
Conductor Size - 6-2 AWG
ERP_productname - BLKBRN CF22-1 CU HTYPE COMP CONN 6 2 STRND CU
Family Brand Name - ABB
Packaging
1 ea
EAN
00783786092215
Part #
326282
Catalog #
CF22-1
Commercial reference
CF22-1
12-Digit UPC:
783786092215
Catalog Number:
CF22-1
Conductor Size:
6-2 AWG
ERP_productname:
BLKBRN CF22-1 CU HTYPE COMP CONN 6 2 STRND CU
Family Brand Name:
ABB
Finish:
Bare
Length:
13/16 Inch
Material:
Copper
Size:
13/16 inch Length
Sub Brand:
Blackburn®
Tc Connection:
Compression
Type:
H-Type Compression Tap Connector
Wire Size:
6-2 SOL CU AWG , 6 STR CU AWG
SoneparProductId:
SKU_US_58981572
Copper H-Type Compression Connector. Wire Range: #6 to #2 Solid Copper or #6 Stranded Copper. Installing Dies: K, W - KK, BKT, B. Features: RUS accepted.; Efficient design requires less crimping force.; Full length tab makes installation easy. Installs with standard compression tools and dies.; Made of pure electrolytic copper to provide hight conductivity. - Notes: Decimal dimensions are for conventional conductor, not Copperweld or Alumoweld.
