Thomas & Betts Co - Blackburn CTL250-12 Compression Terminal
Login or create an account to check prices & order
Essential specifications
12-Digit UPC - 783786131907
Catalog Number - CTL250-12
Color - Yellow
Conductor Size - 250 kcmil
ERP_productname - BLKB CTL25012 250 CU COMP LUG
Packaging
1 ea
EAN
00783786131907
Part #
156237
Catalog #
CTL25012
Commercial reference
CTL25012
12-Digit UPC:
783786131907
Catalog Number:
CTL250-12
Color:
Yellow
Conductor Size:
250 kcmil
ERP_productname:
BLKB CTL25012 250 CU COMP LUG
Family Brand Name:
ABB
Finish:
Tin Plated
Heights:
3 Inch
Material:
Copper
Number of Holes:
1 Hole
Sub Brand:
Blackburn®
Type:
Straight
Voltage:
35 Volt
Widths:
3 in
SoneparProductId:
SKU_US_59361532
Copper One-Hole Lug, Short Barrel, Max 35kV, 250 kcmil Wire, 1/2 Bolt Size, Tin Plated, Die Color Code Yellow Notes: For use with copper conductor: AWG, stranded, flexible cable, welding cable and portable cord. Specially designed for inductrial and building applications. - Features: Color-coded for matching die identification.; Made of high-conductivity seamless copper tubing. Tin plated for corrosion resistance.; Complies with Subpart 111.60-17 of Federal Register's Coast Guard Electrical Engineering Rules and Regulations.; UL Listed for AWG conductor when installed with Blackburn, Burndy, T&B or Andersons Tools.; Specifically chamfered barrel for ease of installation. - Certifications: CSA; UL
