Thomas & Betts Co - Blackburn CTL250L-12 Compression Terminal
Login or create an account to check prices & order
Essential specifications
12-Digit UPC - 783786410408
Applications - For Medium Voltage Applications
Catalog Number - CTL250L-12
Color - Yellow
Conductor Size - 250 kcmil
Packaging
1 ea
EAN
05415022245110
Part #
117147
Catalog #
CTL250L-12
Commercial reference
CTL250L-12
12-Digit UPC:
783786410408
Applications:
For Medium Voltage Applications
Catalog Number:
CTL250L-12
Color:
Yellow
Conductor Size:
250 kcmil
ERP_productname:
BLKB CTL250L-12 COMPR TERMINAL
Family Brand Name:
Thomas & Betts (T&B)
Finish:
Tin Plated
Heights:
3 Inch
Material:
Copper
Number of Holes:
1 Hole
Sub Brand:
Blackburn®
Type:
Long Barrel
Voltage:
35 Volt
Widths:
4 in
SoneparProductId:
SKU_US_59365409
Copper One-Hole Lug, Long Barrel, Max 35kV, 250 kcmil Wire, 1/2 Bolt Size, Tin Plated, Die Color Code Yellow Certifications: CSA; UL - Features: Color-coded for matching die identification.; Complies with Subpart 111.60-17 of Federal Register's Coast Guard Electrical Engineering Rules and Regulations.; Made of high-conductivity seamless copper tubing. Tin plated for corrosion resistance.; Specifically chamfered barrel for ease of installation.; UL Listed for AWG conductor when installed with Blackburn, Burndy, T&B or Andersons Tools. - Notes: For use with copper conductor: AWG, stranded, flexible cable, welding cable and portable cord. Specially designed for inductrial and building applications.
