Thomas & Betts Co - Blackburn CTL40L-12 Compression Terminal
Login or create an account to check prices & order
Essential specifications
12-Digit UPC - 783786410392
Applications - For Copper Conductors
Catalog Number - CTL40L-12
Color - Purple
Conductor Size - 4/0 AWG
Packaging
1 ea
EAN
00783786410392
Part #
195471
Catalog #
CTL40L-12
Commercial reference
CTL40L-12
12-Digit UPC:
783786410392
Applications:
For Copper Conductors
Catalog Number:
CTL40L-12
Color:
Purple
Conductor Size:
4/0 AWG
ERP_productname:
BLKB CTL40L-12 COMPR TERMINAL
Family Brand Name:
ABB
Finish:
Tin Plated
Heights:
3 Inch
Material:
Copper
Number of Holes:
1 Hole
Overall Length:
2-15/16 in
Sub Brand:
Blackburn®
Type:
Long Barrel
Voltage:
35 Volt
Widths:
3 in
SoneparProductId:
SKU_US_58942985
Copper One-Hole Lug, Long Barrel, Max 35kV, 4/0 Str. Wire, 1/2 Bolt Size, Tin Plated, Die Color Code Purple Features: Specifically chamfered barrel for ease of installation.; UL Listed for AWG conductor when installed with Blackburn, Burndy, T&B or Andersons Tools.; Complies with Subpart 111.60-17 of Federal Register's Coast Guard Electrical Engineering Rules and Regulations.; Color-coded for matching die identification.; Made of high-conductivity seamless copper tubing. Tin plated for corrosion resistance. - Notes: For use with copper conductor: AWG, stranded, flexible cable, welding cable and portable cord. Specially designed for inductrial and building applications. - Certifications: UL; CSA
