Thomas & Betts Co - Blackburn CTL4L-14 Compression Terminal
Login or create an account to check prices & order
Essential specifications
12-Digit UPC - 783786410330
Applications - For Copper Conductors
Catalog Number - CTL4L-14
Color - Gray
Conductor Size - 4 AWG
Packaging
1 ea
EAN
00783786410330
Part #
195457
Catalog #
CTL4L-14
Commercial reference
CTL4L-14
12-Digit UPC:
783786410330
Applications:
For Copper Conductors
Catalog Number:
CTL4L-14
Color:
Gray
Conductor Size:
4 AWG
ERP_productname:
BLKB CTL4L-14 COMPR TERMINAL
Family Brand Name:
ABB
Finish:
Tin Plated
Heights:
2.3 Inch
Material:
Copper
Number of Holes:
1 Hole
Overall Length:
1-11/16 in
Sub Brand:
Blackburn®
Type:
Long Barrel
Voltage:
35 Volt
Widths:
2.8 in
SoneparProductId:
SKU_US_58613988
Copper One-Hole Lug, Long Barrel, Max 35kV, 4 Str. Wire, 1/4 Bolt Size, Tin Plated, Die Color Code Gray Features: Complies with Subpart 111.60-17 of Federal Register's Coast Guard Electrical Engineering Rules and Regulations.; Specifically chamfered barrel for ease of installation.; Color-coded for matching die identification.; Made of high-conductivity seamless copper tubing. Tin plated for corrosion resistance.; UL Listed for AWG conductor when installed with Blackburn, Burndy, T&B or Andersons Tools. - Certifications: UL; CSA - Notes: For use with copper conductor: AWG, stranded, flexible cable, welding cable and portable cord. Specially designed for inductrial and building applications.
