Thomas & Betts Co - Blackburn CTL500L-58 Compression Terminal
Login or create an account to check prices & order
Essential specifications
12-Digit UPC - 783786410446
Catalog Number - CTL500L-58
Color - Brown
Conductor Size - 500 kcmil
ERP_productname - BLKB CTL500L-58 COMPR TERMINAL
Packaging
1 ea
EAN
00783786410446
Part #
126228
Catalog #
CTL500L-58
Commercial reference
CTL500L-58
12-Digit UPC:
783786410446
Catalog Number:
CTL500L-58
Color:
Brown
Conductor Size:
500 kcmil
ERP_productname:
BLKB CTL500L-58 COMPR TERMINAL
Family Brand Name:
ABB
Finish:
Tin Plated
Heights:
3 Inch
Material:
Copper
Number of Holes:
1 Hole
Sub Brand:
Blackburn®
Type:
Straight
Voltage:
35 Volt
Widths:
11 in
SoneparProductId:
SKU_US_59364721
Copper One-Hole Lug, Long Barrel, Max 35kV, 500 kcmil Wire, 5/8 Bolt Size, Tin Plated, Die Color Code Brown Certifications: UL; CSA - Features: UL Listed for AWG conductor when installed with Blackburn, Burndy, T&B or Andersons Tools.; Made of high-conductivity seamless copper tubing. Tin plated for corrosion resistance.; Specifically chamfered barrel for ease of installation.; Complies with Subpart 111.60-17 of Federal Register's Coast Guard Electrical Engineering Rules and Regulations.; Color-coded for matching die identification. - Notes: For use with copper conductor: AWG, stranded, flexible cable, welding cable and portable cord. Specially designed for inductrial and building applications.
