Thomas & Betts Co - Blackburn CTL8L-14 Compression Terminal
Login or create an account to check prices & order
Essential specifications
12-Digit UPC - 783786410354
Applications - For Medium Voltage Applications
Catalog Number - CTL8L-14
Color - Red
Conductor Size - 8 AWG
Packaging
1 ea
EAN
00783786410354
Part #
216911
Catalog #
CTL8L-14
Commercial reference
CTL8L-14
12-Digit UPC:
783786410354
Applications:
For Medium Voltage Applications
Catalog Number:
CTL8L-14
Color:
Red
Conductor Size:
8 AWG
ERP_productname:
BLKB CTL8L-14 COMPR TERMINAL
Family Brand Name:
Thomas & Betts (T&B)
Finish:
Tin Plated
Heights:
2.3 Inch
Material:
Copper
Number of Holes:
1 Hole
Sub Brand:
Blackburn®
Type:
Long Barrel
Voltage:
35 Volt
Widths:
2.8 in
SoneparProductId:
SKU_US_30943844
Copper One-Hole Lug, Long Barrel, Max 35kV, 8 Str. Wire, 1/4 Bolt Size, Tin Plated, Die Color Code Red Features: Color-coded for matching die identification.; Specifically chamfered barrel for ease of installation.; UL Listed for AWG conductor when installed with Blackburn, Burndy, T&B or Andersons Tools.; Made of high-conductivity seamless copper tubing. Tin plated for corrosion resistance.; Complies with Subpart 111.60-17 of Federal Register's Coast Guard Electrical Engineering Rules and Regulations. - Certifications: CSA; UL - Notes: For use with copper conductor: AWG, stranded, flexible cable, welding cable and portable cord. Specially designed for inductrial and building applications.
