Thomas & Betts Co - Blackburn CU350 Copper Compression Sleeve
Login or create an account to check prices & order
Essential specifications
12-Digit UPC - 783786132249
Catalog Number - CU350
Color - Red
Conductor Size - 350 kcmil
ERP_productname - BLKB CU350 CU TP SPLICE LONG BRL 350STR RED
Packaging
1 ea
EAN
00783786132249
Part #
112633
Catalog #
CU350
Commercial reference
CU350
12-Digit UPC:
783786132249
Catalog Number:
CU350
Color:
Red
Conductor Size:
350 kcmil
ERP_productname:
BLKB CU350 CU TP SPLICE LONG BRL 350STR RED
Family Brand Name:
ABB
Finish:
Tin Plated
Length:
3-1/4 Inch
Material:
Copper
Sub Brand:
Blackburn®
Type:
Long Barrel Copper Splice
Voltage:
35 kV
Wire Size:
350 kcmil
SoneparProductId:
SKU_US_59361519
Type CU Copper Splice, Long Barrel, 3-3/4 Inch Length, Max 35kV, Wire Size 350 kcmil, Tin Plated, Die Color Code Red Features: Specifically chamfered barrel for ease of installation.; Made of high-conductivity seamless copper tubing. Tin plated for corrosion resistance.; Complies with Subpart 111.60-17 of Federal Register's Coast Guard Electrical Engineering Rules and Regulations.; Color-coded for matching die identification.; UL Listed for AWG conductor when installed with Blackburn, Burndy, T&B or Andersons Tools. - Notes: For use with copper conductor: AWG, stranded, flexible cable, welding cable and portable cord. Specially designed for inductrial and building applications.
