Thomas & Betts Co - Blackburn IKL68 Insulated Service Entry Sleeve

Essential specifications

12-Digit UPC - 783786050376
Applications - For Combinations of Aluminum-to-Aluminum or Aluminum-to-Copper, Stranded Conductors
Catalog Number - IKL68
Color - Pink
Conductor Size - 4/0 AWG ACSR, 4/0 AWG Stranded, 4/0 AWG Compressed, 250 kcmil Compact (End A), 3/0 AWG ACSR, 3/0 AWG Stranded, 3/0 AWG Compressed, 4/0 AWG Compact (End B)

Packaging

100 ea

EAN

00783786050376

Part #

264320

Catalog #

IKL68

Commercial reference

IKL68

12-Digit UPC:

783786050376

Applications:

For Combinations of Aluminum-to-Aluminum or Aluminum-to-Copper, Stranded Conductors

Catalog Number:

IKL68

Color:

Pink

Conductor Size:

4/0 AWG ACSR, 4/0 AWG Stranded, 4/0 AWG Compressed, 250 kcmil Compact (End A), 3/0 AWG ACSR, 3/0 AWG Stranded, 3/0 AWG Compressed, 4/0 AWG Compact (End B)

ERP_productname:

BLKB IKL68 AL SERVENTR SPLICE A:4/0 B:3/0 5.5

Family Brand Name:

Thomas & Betts (T&B)

Length:

5-1/2 Inch

Material:

Aluminum

Number of Conductors:

Size:

4 in

Sub Brand:

Blackburn®

Tc Connection:

Compression

Type:

Insulated, Standard Version, Short Sleeve

Voltage:

600 Volt

SoneparProductId:

SKU_US_58830335

Aluminum 4 inch Service Entrance Compression Splice for Wire Range - Black End: 3/0 ASCR, 3/0 STR, 4/0 CPT, 3/0 CPR. Pink End: 4/0 ASCR, 4/0 STR, 250 CPT, 4/0 CPR. Installing Dies: TX 249 840 (EEI 11A). Compound and Capped. includes 5-7/16 inch Sleeve Features: Concave caps seal out dirt but are easily pierced when inserting conductor. Prefilled with Oxide Inhibitor.; Use for combinations of aluminum-to-aluminum and aluminum-to-copper conductors. Can be used as a low-cost reducing sleeve.; Color-coded and marked for easy identification.; Standards compliant. Meets ANSI C119.4 requirements. Connectors are RUS listed.
