Thomas & Betts Co - Blackburn IKL69 5-1/2" Aluminum Service Entrance Compression Splice. Wire Range - End A: 4/0 ASCR, 4/0 Str., Pink, End B: 4/0 ASCR, 4/0 Str., Pink
Login or create an account to check prices & order
Essential specifications
12-Digit UPC - 783786050383
Applications - Stranded Conductors
Catalog Number - IKL69
Conductor Size - 4/0 AWG
ERP_productname - BLKB IKL69 4/0 TO 4/0 INS SPLICE
Packaging
1 ea
EAN
05415022348897
Part #
157451
Catalog #
IKL69
Commercial reference
IKL69
12-Digit UPC:
783786050383
Applications:
Stranded Conductors
Catalog Number:
IKL69
Conductor Size:
4/0 AWG
ERP_productname:
BLKB IKL69 4/0 TO 4/0 INS SPLICE
Family Brand Name:
ABB
Length:
5-1/2 Inch
Material:
Aluminum
Number of Conductors:
2
Size:
4 in
Sub Brand:
Blackburn®
Tc Connection:
Compression
Type:
Insulated, Standard
SoneparProductId:
SKU_US_58021286
Aluminum 4 inch Service Entrance Compression Splice for Wire Range - Pink End: 4/0 ASCR, 4/0 STR, 250 CPT, 4/0 CPR. Pink End: 4/0 ASCR, 4/0 STR, 250 CPT, 4/0 CPR. Installing Dies: TX 249 840 (EEI 11A). Compound and Capped. includes 5-7/16 inch Sleeve Features: Concave caps seal out dirt but are easily pierced when inserting conductor. Prefilled with Oxide Inhibitor.; Standards compliant. Meets ANSI C119.4 requirements. Connectors are RUS listed.; Color-coded and marked for easy identification.; Use for combinations of aluminum-to-aluminum and aluminum-to-copper conductors. Can be used as a low-cost reducing sleeve.
