Thomas & Betts Co - Thomas & Betts 18RA-516 5/16 Inch Bolt Hole 22-16 AWG Wire Range Red Insulated Vinyl Ring Terminal
Login or create an account to check prices & order
Essential specifications
12-Digit UPC - 786210801018
Catalog Number - 18RA-516
Color - Red
Conductor Size - 22-16 AWG
ERP_productname - TBCO 18RA-516 INS VINYL RING TERM, 22-16, 5/16, R
Packaging
1 ea
EAN
05414363138556
Part #
116865
Catalog #
18RA-516
Commercial reference
18RA-516
12-Digit UPC:
786210801018
Catalog Number:
18RA-516
Color:
Red
Conductor Size:
22-16 AWG
ERP_productname:
TBCO 18RA-516 INS VINYL RING TERM, 22-16, 5/16, R
Family Brand Name:
ABB
Finish:
Electro Tin Plated
Heights:
8.3 Inch
Material:
Copper
Sub Brand:
Sta-Kon®
Type:
Vinyl Insulated Ring Terminal
Voltage:
600 Volt
Widths:
10.4 in
Wire Size:
22-16 AWG
SoneparProductId:
SKU_US_32269956
Vinyl-Insulated Ring Terminal, Length 1.13 Inches, Width .50 Inches, Maximum Insulation .150, Bolt Hole 5/16 Inch, Wire Range #22-#18 AWG, Color Red, Copper, Tin Plated Certifications: UL; CSA - Features: These terminals are self-insulated with a PVC insulation sleeve of extra length to give protection and relieve bending stress at wire's flex point. Brazed seam barrel is serrated to obtain high pull-out value.
