Thomas & Betts Co - Thomas & Betts 54505 Copper 2-Way Splice Connector - Standard Barrel - Blue - #6AWG
Login or create an account to check prices & order
Essential specifications
12-Digit UPC - 786210545059
Applications - Applications certified to 600 V and recommended up to 35 kV.
Catalog Number - 54505
Color - Blue
Conductor Size - 6 AWG
Packaging
1 ea
EAN
05414363110576
Part #
158925
Catalog #
54505
Commercial reference
54505
12-Digit UPC:
786210545059
Applications:
Applications certified to 600 V and recommended up to 35 kV.
Catalog Number:
54505
Color:
Blue
Conductor Size:
6 AWG
ERP_productname:
TBCO 54505 2WAY SPLICE CONNECTOR #6
Family Brand Name:
ABB
Finish:
Tin Plated
Material:
Copper
Sub Brand:
Color-Keyed®
Type:
2 Way
Voltage:
600 Volt
Wire Size:
6 AWG
SoneparProductId:
SKU_US_25686174
Copper Two-Way Splice Connector, Standard Barrel, Max 35kV, Wire Size 6 AWG, Tin Plated, Die Code 24, Die Color Code Blue Features: Two-way connectors provide high pullout values, are easy to insulate and provide a low-resistance connection of high quality and low installed cost.
