Thomas & Betts Co - Thomas & Betts B14-4 18 to 14 AWG #4 Stud Metallic Electrotinned Copper Non-Insulated Ring Terminal
Login or create an account to check prices & order
Essential specifications
12-Digit UPC - 786210803142
Catalog Number - B14-4
Color - Metallic
Conductor Size - 18-14 AWG
ERP_productname - CARB B14-4 NON-INS RING TRM 18-14 NO4 METAL
Packaging
1 ea
EAN
05414363148432
Part #
274950
Catalog #
B14-4
Commercial reference
B14-4
12-Digit UPC:
786210803142
Catalog Number:
B14-4
Color:
Metallic
Conductor Size:
18-14 AWG
ERP_productname:
CARB B14-4 NON-INS RING TRM 18-14 NO4 METAL
Family Brand Name:
ABB
Finish:
Electro Tin Plated
Heights:
3 Inch
Material:
Copper
Sub Brand:
Sta-Kon®
Type:
Short Sleeve
Voltage:
600 Volt
Widths:
1.63 in
Wire Size:
18-14 AWG
SoneparProductId:
SKU_US_25468134
Non-Insulated Ring Terminal, Length .72 Inches, Width .25 Inches, Bolt Hole #4, Wire Range #18-#14 AWG, Copper, Tin Plated Features: These non-insulated ring terminals are made of electrolytic copper for high conductivity. They can be installed with crimping tools having a single indentor or double indentor (recommended for solid wire). Serrated barrel increases grip on wire. - Certifications: CSA; UL
