Thomas & Betts Co - Thomas & Betts D8-12 8-1/2 Inch 8 AWG Stud Non-Insulated Ring Terminal
Login or create an account to check prices & order
Essential specifications
12-Digit UPC - 786210878430
Catalog Number - D8-12
Color - Metallic
Conductor Size - 8 AWG
ERP_productname - TBCO D8-12 NONINS BS RNG TERM NO8 AWG 1/2 BOLT
Packaging
1 ea
EAN
05414363150138
Part #
123980
Catalog #
D8-12
Commercial reference
D8-12
12-Digit UPC:
786210878430
Catalog Number:
D8-12
Color:
Metallic
Conductor Size:
8 AWG
ERP_productname:
TBCO D8-12 NONINS BS RNG TERM NO8 AWG 1/2 BOLT
Family Brand Name:
ABB
Finish:
Electro Tin Plated
Heights:
2.9 Inch
Material:
Copper
Sub Brand:
Sta-Kon®
Type:
Short Sleeve
Voltage:
600 Volt
Widths:
1.1 in
Wire Size:
8 AWG
SoneparProductId:
SKU_US_29916335
Non-Insulated Large Brazed Seam Ring Terminal, Length 1.49 Inches, Width .82 Inches, Bolt Hole 1/2 Inch, Wire Range #8 AWG, Copper, Tin Plated Features: These non-insulated ring terminals are made of electrolytic copper for high conductivity. They can be installed with crimping tools having a single indentor or double indentor (recommended for solid wire). Serrated barrel increases grip on wire. - Certifications: CSA; UL - Notes: Not available on Mylar Tape.
