Thomas & Betts Co - Thomas & Betts EXUN-1 1/2 Inch Aluminum Explosion Proof 5-Hole Box
Login or create an account to check prices & order
Essential specifications
12-Digit UPC - 042269347458
Applications - For Junction Branch Conduits in Hazardous Locations
Catalog Number - EXUN-1
ERP_productname - RDOT EXUN-1 1/2 INCH 5-HOLE BOX, ALUM, XP
Family Brand Name - ABB
Packaging
1 ea
EAN
00042269347458
Part #
138845
Catalog #
EXUN-1
Commercial reference
EXUN-1
12-Digit UPC:
042269347458
Applications:
For Junction Branch Conduits in Hazardous Locations
Catalog Number:
EXUN-1
ERP_productname:
RDOT EXUN-1 1/2 INCH 5-HOLE BOX, ALUM, XP
Family Brand Name:
ABB
Material:
Aluminum
Mounting Type:
Surface
Sub Brand:
Red Dot®
Type:
5-Inlet
Widths:
100.8 mm
SoneparProductId:
SKU_US_58178463
1/2 Inch Hazardous Location Internal Hub with Installed Green Ground Screw, Die Cast Aluminum, 5 Outlets with 3 Close Up Plugs, 20.3 Cubic Inch Features: Precision NPT threaded hubs allow trouble-free field installation for rigid or IMC conduit.; Die cast construction and industrial design combine to produce a rugged protective enclosure for devices on industrial and OEM applications.; Precision cast and machined surfaces permit safer wire pulling. - Application: Junction for branch conduits in hazardous locations. - Notes: NEMA 3, 4, 7 CD, 9 EFG - Wet Locations; Class I, Div. 1&2, Groups C, D - Explosionproof; Class II, Div. 1, Groups E, F, G - Dust-Ignitionproof; Class III, Div. 1&2 - Raintight - Certifications: UL
