Wago - Wago 221-612 2-Conductor #10 AWG Push-In LEVER-NUTS® Wire Splicing Connector, #20-#10 Solid/Stranded, Clear w/Orange Lever (Box of 50)

CopyCopy

Login or create an account to check prices & order

Essential specifications

  • 12-Digit UPC - 4055143704168

  • Actuator - Lever

  • Catalog Number - 221-612

  • Color - Transparent

  • Conductor Material - Copper

Packaging

  • 1 ea

EAN

Part #

151425

Catalog #

221-612

Commercial reference

221-612

12-Digit UPC:

4055143704168

Actuator:

Lever

Catalog Number:

221-612

Color:

Transparent

Conductor Material:

Copper

Conductor Size:

10 AWG

Country of Origin:

Switzerland

Current:

41 Amp

Depths:

0.831 Inch

ERP_productname:

WAGO 221-612 2 PORT LEVER NUT FOR 10AWG 50/BOX

Family Brand Name:

Wago

Heights:

0.398 Inch

Widths:

0.63 in

SoneparProductId:

SKU_US_25782822

WAGO 221-612 2 PORT LEVER NUT FOR 10AWG 50/BOX Features: Ease of use . pull the lever up, insert a conductor and push the lever back down; Available as 2-, 3- and 5-wire connectors; Easily terminate conductors from 0.5 to 6 mm²; Connection of all conductor types; Time savings for installers and device manufacturers; Quickly install devices with higher power consumption; Safely install long cable runs with larger conductor cross sections; Mounting carrier for installation conforms to standards; Custom carriers are possible - Approvals: DEKRA Certification B.V., ENEC 05, 71-123784, EN 60998; Lloyds Register, LR, LR22207029TA, EN 60998; American Bureau of Shipping, ABS, 18-HG1755093-PDA, EN 60998; UL International Germany GmbH, UL, E69654, UL 486C; Det Norske Veritas, Germanischer Lloyd, DNV GL, TAE000015T, EN 60998; UL International Germany GmbH, UL_Listed_64KA, E201573, UL 467; DEKRA Certification B.V., CB, NL-81003, IEC 60998 - Accessory Products: 207-1431; 207-1432; 207-1433; 221-510; 221-510/000-006; 221-510/000-053; 221-941; 221-941/000-006; 221-942; 221-942/000-006
