Burndy BGBL250 Aluminum Lay-in Lug, 250 kcmil-#6 AWG, 7/16" Stud, Tin Plated

Manufacturer: Burndy | Catalog # BGBL-250 | Echo Electric Part # 139503
$17.69/ea
ea
Log in or register to view your price, purchase history, and more!
0

Not Available for Pickup at Springfield, IL Opens Monday 7:00am CT
78 available

For Delivery

Not in local stock *
Check another branch
Buy American Compliant Buy American Compliant Product Spec Sheet
Aluminum Lay-in Lug, 250 kcmil-#6 AWG, 7/16" Stud, Tin Plated.

Technical Information

Applications
For Copper And Aluminum Conductor Combinations Up To 90 DEG C, 600 Volt Applications
Bolt Size
7/16-18, 7/32 IN Hex
Conductor Material
Aluminum and Copper
Conductor Size
6 AWG-250 kcmil
Material
Aluminum
Max Voltage
600 V
Mounting Hole Size
0.28 in
Plated?
Yes
Plating Type
Tin
Stud Size
7/16-18
Temperature Rating
90 degrees C
Type
BGBL
Voltage
600 Volt

Manufacturer Information

Brand
Burndy
Sub Brand
Qiklug™

General Product Info

12-Digit UPC
781810124819
Finish
Electro-Tin Plated
GTiN
00781810124819
Product UPC
78181012481

Dimensions

Height
1.79 Inch
Hole Size
0.33 in
Length
2.2 Inch
Overall Length
56 mm
Width
0.80 in

Certifications and Compliance

Buy American Compliant
Y
Country of Origin
USA
CSA
Yes
Features
  • UL486B Listed, AL9CU Rated for copper and aluminum conductor combinations up to 90°C
  • UL Recognized for grounding and bonding
  • Lay-in feature eases installation
