Hubbell SBSB1A Spider® II Temporary Power Box, Straight Blade, with 7) 20A 125V Straight Blade Receptacles, 1) 50A 125/250V Locking Inlet and 1) 50A 125/250V Locking Outlet

Manufacturer: Hubbell Wiring Device | Catalog # SBSB1A | Echo Electric Part # 140043
$3,003.19/ea
ea
Log in or register to view your price, purchase history, and more!
Usually ships within 8 to 12 days
Product Spec Sheet Product Catalog Page Installation / Instruction Manual
Temporary Power Products, Spider Portable Power, Complete Unit, Straight Blade Style, With 7) 20A 125V Straight Blade Receptacles, 1) 50A, 125/250V Locking Inlet and 1) 50A 125/250V Locking Outlet

Technical Information

Amperage
50 Amp
Applications
Heavy Duty Portable
Conductor Size
10 AWG
Current
50 Amp
Material
Thermoplastic
NEMA
5-20R,50A,In/Out
Number of Phases
1 Phase
Number of Poles
3-3 Pole
Number of Wires
4,4
Size
Standard Sized Product
TC Connection
Pre-Wired
Type
1-50A,1-50A 125,125,125V Straight Blade Receptacles,250V Locking Inlet,250V Locking Outlet,7-20A
Voltage
120/240 Volt
Wattage
12500 Watt
Wire Size
10 AWG

Manufacturer Information

Brand
Hubbell Incorporated
Sub Brand
Spider Temporary Wiring Products

General Product Info

12-Digit UPC
783585370873
Color
Yellow
Environmental Conditions
Indoor and Outdoor
GTiN
00783585370873
Product Series
Spider II
Product UPC
78358537087

Dimensions

Height
14.2 Inch
Length
23.1 Inch
Width
19.800 in

Certifications and Compliance

Country of Origin
USA
Features
  • Individual GFCI modules
  • TYPE 3R metallic enclosure and heavy duty,abuse resistant legs
  • Standard stab termination circuit breakers with gasketed lift cover
  • Standard Product
